Watch Case Design – ETA 2895-2 (Project V2) and Dial design Blind
in
3D Modeling Design
held by
yamant
Last seen:
Contest Ended, Winner(s) have been selected.
-
Open
-
Choosing Finalist
-
Ended
Description:
I’m developing a high-end custom watch case to house the ETA 2895-2 automatic movement.The case should blend modern tool-watch strength with refined luxury finishing—featuring a crown-guard lever inspired by Panerai yet with a distinct and original geometry.
REQUIREMENTS
• Outer diameter (without crown guard): ~42 mm
• Width including crown guard: ~47 mm
• Lug-to-lug length: ~48.5 mm
• Overall thickness: ~11.5 mm (including sapphire front and exhibition caseback)
• Lug width: 22 mm
• Crown-guard dimensions: ~23.5 mm bridge length, ~14 mm width, ~3 mm protrusion
• Material: 316L stainless steel (option for 904L)
• Front crystal: Sapphire (flat or slightly domed), ~1.2 mm, AR-coated
• Caseback: Sapphire exhibition, screw-down, ~1.0 mm
• Water resistance: minimum 50 m
• Movement ring/spacer: for ETA 2895-2
Deliverables:
• 3D CAD model of the complete case (STEP / IGES / STL)
• Model must ensure proper fit for the ETA 2895-2 movement
• Dial + hands seat dimensions included
• Optional render or screenshot previews
Two case finishes are requested:
1. Polished metallic version
2. Brushed steel version
Attached references include the visual renders and dimensional sketch.
For the Dial
General Specifications:
• Diameter: 29.0–29.5 mm
• Thickness: 0.4–0.5 mm (brass base with engine-turned guilloché, lacquer/enamel finish)
• Layout: Central hours & minutes; small seconds at 6 o’clock (~10 mm subdial integrated into guilloché pattern)
• Feet: ETA 2895-2 standard positions (~2:30 & 8:30)
• Indices: Applied spheres or batons (rhodium/polished steel)
• Hands: Dauphine or leaf, compatible with blued and polished steel hands
• Logo/Text: “YT” logo under 12 o’clock; optional “AUTOMATIC” above 6 o’clock
Dial A – Silver
• Guilloché wave pattern, silver/white finish
• Rhodium indices
• Blued dauphine/leaf hands
Dial B – Green
• Guilloché wave pattern, deep green enamel finish
• Rhodium indices
• Polished steel dauphine/leaf hands
Deliverables:
• 3D CAD models (STEP / IGES / STL) ready for dial manufacturing
• Accurate feet placement for ETA 2895-2
• Clean guilloché surface geometry
• Optional render previews of each dial color
Reference visuals (attached):
1 – Silver dial mock-up
2 – Green dial mock-up
Wants:
Accuracy of movement fit (ETA 2895-2)• Realistic manufacturing geometry (no unmachinable details)
• Aesthetic refinement and proportion balance
• Clean crown-guard and lug integration
• File quality (STEP/IGES + complete geometry)
Accuracy of Dial
Accuracy of movement fit (feet positions)
• Guilloché pattern quality and realism
• Manufacturing feasibility (CNC/CAM ready geometry)
• Aesthetic proportion and finishing realism
• File quality and organization
Don't Wants:
• Generic off-the-shelf watch shapes• Copies of existing Panerai or other branded cases
• Unrealistic or overly conceptual art models
• Files that cannot be manufactured
For Dial:
• Flat 2D drawings or Photoshop visuals only
• Unrealistic conceptual dials with no manufacturable geometry
• Incorrect feet placement or movement spacing
Ask for Sample:
Please include one preview render or screenshot showing the model from front and side before final file delivery.
Software:
- SolidWorks 2021 or later / Fusion 360 / Rhinoceros (Any version able to export STEP (.stp) or IGES (.igs))
Additional Information
CAD DRAWING!!!I am requiring a 3D CAD Model
Prepaid PrizeEntries
1st Winner
#24 Watch case ETA 2895-2
by Design And More
#1 Aurum 2895-High- end gold watch ETA2895 - 2 movement red scond- hand
by monirh
Declined
Download Files
#15 STEP Case watch
by Manp
Download Files
#28 Custom Watch Case 42mm ETA 2895-2
by ezgu1
Download Files
#27 Watch Case
by Inerapello
Download Files
#26 YT Watch Case Design (ETA 2895-2)
by 3Dlabworks
#25 Watch Case Design – ETA 2895-2 (Project V2) and Dial design
by TFC
Download Files
#23 01GWh
by Zulfadzryl
Download Files
#22 Watch Case Design – ETA 2895-2 (Project V2) and Dial design
by Kzswara
#21 Watch Case Design – ETA 2895-2 (Project V2) and Dial design
by Kzswara
#20 Halo
by avatard
Download Files
#19 Custom_WatchCase_ETA2895-2_by_Samikshya
by samikshya_ghimire
Download Files
#18 Wrist Watch Case Design
by Mahbub
Download Files
#17 Watch Case Design – ETA 2895-2 (V2) by Ange Claver
by Etche_ange_claver
Download Files
#16 Watch Case Design – ETA 2895-2 (Project V2) and Dial design
by Manp
Download Files
#14 YT CRONOS
by spacedeveloper
Download Files
#13 YT Vanguardia
by NextGen_IoT_LAB
#12 Watch
by Manp
Download Files
#11 Watchcase
by clintsar
Download Files
#10 Watch_Cases
by romd
#9 Watch Case Design – ETA 2895-2 (Project V2) and Dial design
by HawT3D
Download Files
#8 Watch Case Design – ETA 2895-2 (Project V2) and Dial design
by HawT3D
#6 Omnibus Delikatesse
by jaedonl
Download Files
#5 Omnibus Delikatesse
by jaedonl
Download Files
#4 Aether watch
by Rira-f
#3 White_YT
by hassanc
Download Files
#2 YT Époque – (French for “era,” suggesting timeless luxury)
by NextGen_IoT_LAB
