Tankless water heaterBlind
in
3D Modeling Design
held by
gordono
Last seen:
Contest Ended, Winner(s) have been selected.
-
Open
-
Choosing Finalist
-
Ended
Description:
Design a tankless water heater. Something different yet pleasing to the eye. If it was in your home, Laundry room, garage, utility closet. Something futuristic, yet simple and doesn't stand out too much. No buttons or LCD screen. Can have LEDs and so forth to make the design better and stand out a little. The file will need to be able to convert and use. 3D model this and then put it into 3d rendering to make it look good. Use what software you want long as we can utilize the file for later purposes. First place will continue working with us on the design for including full case design for manufacturing, and other renderings of the design along with the inside for mounting parts.
For now, we are looking for the best design and someone that will be able to help in the area listed above for future work.
Wants:
Can be any shape, size will be in these constraints. MAX 3 feet wide by 3feet long by 1foot depth and Minimum is 1Foot wide 1Foot length and 6Inch depth. must fall into those constraints. If the unit is round then can sacrifice wide length for depth. So you have a lot to work with. Make it simply does not have to be super complex. The unit will need to be able to hand on a wall you will have one inlet one outlet and a power plug-in. 3D rendering after to have as close as possible photo realistic product.
Don't Wants:
Overly complex
Ask for Sample:
One sample of the front and side of the unit.
Additional Information
Add a QR code on unit this is where people will connect the unit through the app. As well as add our logo to the unit. It will be attached. This is an electric tankless.
** Update ** going to give the design some extra design considerations for flexibility. The depth we are going to expand to 3foot. If the width is taken in. This should help in design flexibility and out-of-the-box ideas.
***Update 2: The unit's temp is controlled by the app. Water flow is not important at this point meaning the connectors inlet and outlet just run at 1/2" or 3/4" pipe. Not important at this stage.
This is going in a home so not industrial.
No need for LCD screens as displays however can add LED however you see fit or cut outs that are see-through etc.
At this stage, we are looking for design.
Prepaid PrizeEntries
#71 Tankless water heater
by ayoubd
Download Files
- AutoCAD 2019 — Tankless Water Heater- with LED Display
- PDF — Tankless Heater Water-Isometric View
- PDF — Tankless Heater Water-Front View
- PDF — Tankless Heater Water-Top View
- PDF — Tankless Heater Water-Sample-Side View-
- PDF — Tankless water heater Sample-Front View-
- PDF — Tankless Water Heater-Presentation
Jun 1, 2021 0:34
Discussion
Showing last 20 comments - View All
Interesting project...........................................Thank you for the contest ! :)
haitham: temp reading is through app. You can use what color you believe will look the best for in a home. Doors you can put anything thing you like. Just logo and QR code.
Hiq
The QR cone is in incorrect png format.Could you upload it in normal png format without background
The QR cone is in incorrect png format.Could you upload it in normal png format without background
Hi
QR code to be added , name of company or it will be only logo?
Thanks
QR code to be added , name of company or it will be only logo?
Thanks
Any doors?
No temperature reading?
Specific color?
alphinm: Flow rate can be 4GPM and as low as 2GMP. However, this is not as important due to just designing the outside looks.
Temperature can be controlled using the app. Range 60-140. Dont need LCD screens and so forth due running through app. How many people check that lcd screen unless something breaks and first setting it up.
Temperature can be controlled using the app. Range 60-140. Dont need LCD screens and so forth due running through app. How many people check that lcd screen unless something breaks and first setting it up.
GalaxyRobotics: This is more simplistic/stylish will be going into a home, not a work area.
Please specify the following details:
1) Flow rate.
2) Can the temperature be controlled using the app. If thats the case what is the range of temperature required ?
*please provide the above information so that I can design a good model.
1) Flow rate.
2) Can the temperature be controlled using the app. If thats the case what is the range of temperature required ?
*please provide the above information so that I can design a good model.
Hello, gordono!
Thank you for this interesting contest. I just had a quick question for you to clear up.
Would you like the design to be more heavy-duty/ industrial looking, or more simplistic / stylish?
Thank you again, I am excited to work on this project.
@GalaxyRobotics
Thank you for this interesting contest. I just had a quick question for you to clear up.
Would you like the design to be more heavy-duty/ industrial looking, or more simplistic / stylish?
Thank you again, I am excited to work on this project.
@GalaxyRobotics
atekd: Yes that is the max of the unit. So nothing over that. But also have some design room so if you go wider the height will have to decrease. Keep the depth to a minimum though 1 foot is ideal.
Are the dimensions correct 3 feet (H) x 3 feet (W)x 1 feet (D)
Vijay Dwivedi: Just the exterior of the unit. When we choose someone we will have them finish up design as the project moves forward for adding brackets and so forth into the design.
sherifelsheikh: this is electric tankless
stanislavp: The unit will be a while home unit. Works for single point of use are also in the works. But power and electronics change. We are not to that point yet. But will develop in future. We are not needing any main controls due to unit being adjustable through an app on phone. Passive light controls will be good for diagnosis of unit. Implement them how ever you see fit.
hello,
do you want the internal heating element and electronics placement in the prototype , or just the exterior of it?
do you want the internal heating element and electronics placement in the prototype , or just the exterior of it?
Hello, Thank you for this interesting contest.
Do you mean gas tankless water heater?
Do you mean gas tankless water heater?
Hello,
Thank you for publishing an interesting contest. A couple of questions for better understanding of the product application and correlated engineering goals. Do you plan to position a heater as a whole-home supply unit* or just as a point of usage? Did you definitely decided to extremely simplify user interface by eliminating any control elements except passive light indicators or it's up to designer to offer the best solution to make it equipped with temperature adjustment?
*A flow-through parameter, power consumption and eventually product dimensions may sufficiently vary. For example:
Kitchen sink, standard shower head, dishwasher or washing machine: up to 2 Gallons per minute
Bath tub: up to 4 GPM
Whole-home up to 6 GPM
Best Regards,
Stanislav
Thank you for publishing an interesting contest. A couple of questions for better understanding of the product application and correlated engineering goals. Do you plan to position a heater as a whole-home supply unit* or just as a point of usage? Did you definitely decided to extremely simplify user interface by eliminating any control elements except passive light indicators or it's up to designer to offer the best solution to make it equipped with temperature adjustment?
*A flow-through parameter, power consumption and eventually product dimensions may sufficiently vary. For example:
Kitchen sink, standard shower head, dishwasher or washing machine: up to 2 Gallons per minute
Bath tub: up to 4 GPM
Whole-home up to 6 GPM
Best Regards,
Stanislav
It is best to fit in the dimensions. Due to the internals. However, if you have a design that is a little bigger. I would not be apposed. But main factors will be in those constraints. This is also on going and sizes may change over time. Thanks
