Description:
We are planning to launch a fixed version of our mobile DC fast charging and energy storage system. We would like to improve the exterior aesthetics of the system, making it appear more contemporary, but changing the shape, materials, the user interface, cable management, etc. Any way to make it more appealing and intuitive to a customer who needs to charge their vehicle.
Wants:
Originality, intuitive UI, adaptable materials,
Don't Wants:
A logo or color change. We want something that keeps a similar form factor but changes the aesthetics and usability of the system to make it more appealing to non-industrial users and to make it more architecturally appealing.
