Description:
Create a PCB for a 13.56MHz RFID PoE Reader with an ESP32, an LED, a buzzer, and a USB C port. The board must be able to quickly and reliably send HTTP POST requests, then flash green or red (and beep) based on the HTTP status code returned (include a minimal .ino file to demonstrate this).Ensure the board can receive data and power via PoE, and firmware can be flashed via the USB C port.
A compact design is preferred, but ensure there is no interference between any components, specifically the connectivity and RFID.
Please include PCB schematics, Gerber files, BOM, enclosure sketches, 3D renderings, and the minimial .ino file.
Please add in-progress entries in phases—PCB schematic, component placement draft, then final layout—and I’ll provide feedback promptly.
Wants:
- Quick and reliable HTTP POST responses on tap- LED and beep according to POST response code
- Any 13.56MHz RFID/NFC card is detected within about 18cm
Don't Wants:
- Any delay in the speed of the requests/taps (taps should be successfully processed at a rate of at least 1 tap/second)- Any unreliability in the connection (POSTs failing, timing out, etc.)
Ask for Sample:
Please provide a sample board and a minimal .ino file.
