I will convert your 2D engineering drawing into a 3D CAD model
About this service
Need a 3D CAD model created from an existing 2D drawing?
I will accurately model your part from a dimensioned engineering drawing and deliver a clean, ready-to-use STEP (.STEP/.STP) file.
What's included:
- 1 mechanical part
- Conversion from a dimensioned 2D drawing to 3D
- Basic fillets, chamfers, holes, pockets, and other standard features
- STEP file delivery
- 1 revision
- 24-hour delivery for straightforward parts
Accepted source files:
- PDF
- JPG/PNG
- DXF
- Other common 2D drawing formats
Deliverable:
- STEP (.STEP/.STP)
Please message me before ordering if the part is unusually complex or the drawing contains multiple parts.
