Protective Plexiglass Enclosure for Industrial Mixer

Report
This project involved designing a custom protective Plexiglass enclosure for an existing industrial mixer using FreeCAD. The objective was to verify the external dimensions, ensure proper fit before manufacturing, and facilitate the fabrication and installation process. Skills demonstrated: • 3D CAD Modeling • Mechanical Design • Reverse Engineering • Design for Manufacturing (DFM) • FreeCAD
