PCB Design of Super Computer Mainboard and Embedded Devices

Report
The PCB Design of Super-Computer Mainboard. - 24Gbps PCIe Gen4, 12Gbps PCIe Gen3, DDR4 DIMM, SSD, SATA, - HDMI, USB3.1, 100MHz Ethernet, SD Card, DVI, VGA, - SPI, UART, RS485, RS232, I2C) The PCB Design of Large-Scale Broadcasting System Mainboard. -A great deal of video and audio signal processing - multi-path analog signal input/output processing - multi-path Ethernet signal processing - DDR4, DVI, VGA, HDMI, SPI, UART, USART, RS485, RS232, I2C The PCB design of the Gen 6464-12G Signal Generator Mainboard. - 12Gbps high speed signal processing - DDR4, video and audio signal processing I hope that my experience and knowledge of years will contribute to the success of more client's projects.
