ESP32 WROOM 32

The ESP32-WROOM-32 is a powerful Wi-Fi + Bluetooth module developed by Espressif Systems. It’s built around the ESP32-D0WDQ6 (or ESP32-D0WD) chip, which integrates: Dual-core Xtensa® 32-bit LX6 microprocessor (up to 240 MHz) Integrated Wi-Fi 802.11 b/g/n Bluetooth v4.2 BR/EDR and BLE Rich peripheral interfaces Key Features Processor: Dual-core 32-bit Xtensa® LX6 CPU, up to 600 DMIPS RAM: 520 KB SRAM (on-chip) Flash Memory: 4 MB (in standard WROOM-32 module) Wireless: Wi-Fi 802.11 b/g/n (2.4 GHz) Bluetooth v4.2 (Classic + BLE) I/O Interfaces: 34 programmable GPIOs UART, SPI, I²C, I²S, CAN, PWM 12-bit SAR ADC (up to 18 channels) 2 × 8-bit DACs Touch sensors Power: 3.0V–3.6V operating voltage, deep-sleep current ~5 μA Operating Temperature: –40 °C to +85 °C Physical Description Package: 38-pin SMD module, metal RF shield Size: 18 mm × 25.5 mm × 3.1 mm Antenna: Onboard PCB antenna (with U.FL connector in some variants) Applications Smart home (lights, sensors, voice assistants) Wearables & healthcare devices Industrial automation and robotics IoT gateways and data loggers Wireless audio (via I²S + Bluetooth)
