works portofolio

1- An advanced rotating part project implementing backward-curved vane splines optimized for fluid dynamics and cavitation resistance. Designed with Stainless Steel-316 specifications embedded into the custom BOM table for chemical compatibility with refined hydrocarbons. 2- Industrial 4-Inch Flange Design (ASME/ANSI Class 150): A precision structural component modeled from raw dimensions into a fully dimensioned manufacturing blueprint. 3-Fuel Unloading & Bulk Storage P&ID: A comprehensive system-wide infrastructure schematic incorporating manual suction-side isolation, discharge-side backflow prevention, and continuous 4-20 mA An automated safety instrument interlocks. 4-Modular Pump Skid System: engineered to execute rapid, high-integrity fluid containment transfer protocols. The structural framework is fabricated from structural-grade carbon steel and C-channels conforming to AWS D1.1 structural welding code, providing high torsional resistance against vibrational stresses generated during heavy-duty cycles. 5-an industrial Ergonomic Control Handle Grip was constructed using a multi-station skeletal layout framework.
