I will design 2 to 12 layer kicad pcb with controlled impedance, drc and gerber files
About this service
Professional KiCad PCB design for complex multilayer and high speed boards. Whether you need a 2-layer signal board or a 12-layer HDI design with controlled impedance, I deliver production ready layouts every time.
What I design:
- 2 to 12 layer KiCad PCB layouts
- High-speed digital: DDR3/4, PCIe, USB 3.0, HDMI
- RF and mixed-signal boards
- Power electronics and motor drivers
- IoT, ESP32, STM32, Raspberry Pi carrier boards
- Industrial, automotive, and medical grade layouts
Every delivery includes:
- Gerber files (all layers) + Excellon drill files
- Bill of Materials (BOM)
- Pick & Place (centroid) file
️- DRC passed zero errors, zero warnings
- KiCad source files
My design approach:
I follow IPC-2221 standards, apply proper power and ground plane strategies, manage signal integrity through controlled impedance trace routing, and ensure your board is fabrication ready for JLCPCB and PCBWay.
Message me before ordering I'll review your schematic/requirements and suggest the right package.
