Three-module site cabin · plan, elevations, foundations and render

Sample project. Three modules, 6000 by 7200 mm, an exposed concrete frame and a glazed envelope with black joinery. Behind the render of the furnished cabin come the general plan with the three elevations, the envelope detail and the joinery and electrical panel schedules, plus the foundation sheet: perimeter strip footing and the two internal ones under the module joints, section at 1:20 with the slab reinforced over a gravel sub-base, and the footing reinforcement at 1:10.
foundation construction-drawings modular-building prefab site-cabin
