Structural Mild Steel L-Bracket | GD&T Engineering Drawing

Designed a structural L-bracket in SolidWorks to ASME Y14.5 drafting standards. The part features a gusseted profile for load bearing, a precision Ø25mm bore with unilateral tolerance, and dual Ø10mm mounting holes. Delivered a fully dimensioned engineering drawing including GD&T callouts (perpendicularity, true position, cylindricity, flatness), section view, material specification (ASTM A36 mild steel), surface finish callout and general manufacturing notes. Drawing produced at 1:2 scale with revision control.
