screenshot_in_Fusion360_Manufacture

Hello, I am a Mechanical Design Engineer with extensive experience developing manufacturing-ready 3D CAD models for consumer products, including parts intended for injection molding, silicone molding, and 3D printing. I work primarily in Fusion 360 and deliver production-ready CAD along with complete technical documentation. Your project is a great fit for my experience. I understand that this is not simply a cosmetic model—the silicone boot must fit the Owala FreeSip 24 oz bottle accurately while also being optimized for compression molding and future LSR production. For this project, I can provide: • A fully parametric 3D CAD model (editable source file + STEP) • STL files for prototyping • Manufacturing-ready 2D technical drawings with dimensions, wall thickness, draft angles, parting lines, and section views • Detailed cross-section of the charm socket geometry • DFM recommendations for food-grade silicone molding • Design optimized for consistent wall thickness, mold release, durability, and manufacturability I pay close attention to: * Proper draft angles for silicone molds * Uniform wall thickness to reduce molding defects * Compression molding best practices * Clean transitions between thin walls and the reinforced charm band * Drainage features and flexible snap-fit socket geometry * Easy future modification if transitioning to Liquid Silicone Rubber (LSR) tooling If you provide the reference bottle, existing boot, and design brief, I will accurately model the geometry and ensure a precise fit while maintaining a manufacturable design. I communicate regularly throughout the project and can provide design previews for approval before finalizing the manufacturing files. I would be happy to discuss your project and help bring it to production. Thank you for your time, and I look forward to working with you.
