PURELY SHEET METAL DESIGN FOR A 1.5M DIAMETER BY 1.5M HIGH CONCRETE MOLD

The project requires the modelling, analysis, structural optimization, and fabrication of an airport control tower steel frame, landind floors and an emergency monkey ladder to serve the tower in the high temperature and windy region of Nigeria. ROLE: Design Engineer ix. Solidworks for modelling using Sheetmetal and weldments. x. ANYS workbench for static analysis to optimize and validate design using the result of the static, the modal, and fatigue analysis. xi. Excel for BOM/BOQ. xii. Solid works for shop, fabrication and installation drawing. iv. Libelula plasma cutting software for sheet metals part cutting optimization.
