Professional Patent Drawings - USPTO Compliant

Design Patent Drawings (USPTO Registered) This portfolio showcase includes a series of high-precision line drawings for design patents that have been successfully registered with the USPTO. Key Features: Full Compliance: All drawings are created in strict accordance with USPTO's formal requirements, including precise line weights, hatching, and perspective views. Technical Accuracy: Expertly translated complex 3D CAD data into clean, professional 2D technical illustrations. Proven Results: These drawings contributed to the successful issuance of patent numbers such as US D1,087,866 S and others shown in the files. I specialize in transforming industrial designs into production-ready and legally-compliant patent illustrations.
