Mechanical Flange Technical Drawing

This is a technical drawing and 3D CAD model of a mechanical flange used for connecting pipes in industrial applications. The design includes specific dimensions (e.g., Ø18, Ø34 holes, R8 fillets) and angular specifications (55°, 35°) as detailed in the provided PNG image The model is ready for manufacturing or integration into a larger assembly.
