Industrial Sheet Metal Detailing & Fabrication Drawings

Development of detailed industrial sheet metal fabrication drawings based on 3D models, existing equipment, or client data. The work included complete shop drawings, weld details, cut lists, assemblies, and manufacturing documentation ready for production. Projects involved complex industrial equipment requiring high dimensional accuracy, proper tolerances, and fabrication feasibility. Deliverables were created to support manufacturing teams, reducing installation errors and improving assembly efficiency in industrial environments.
