Industrial Power Transmission System - SolidWorks Mechanical Design

Report
Designed and developed an Industrial Power Transmission System in SolidWorks, including 3D modeling, mechanical assembly design, power transmission components, and detailed manufacturing documentation. The assembly incorporates an electric motor, flexible coupling, shafts, bearing units, sprockets and roller chain, mounting components, and protective guards. Deliverables include detailed 3D models, complete assembly design, exploded views, BOM, assembly drawings, manufacturing drawings, and high-quality rendered views. Design considerations included manufacturability, shaft and bearing alignment, component accessibility, assembly efficiency, maintenance, and safe guarding of rotating components.
Published
in Mechanical Engineering SolidWorks Design Services Mechanical Design Services
solidworks bearing shaft 3d-modeling mechanical-design machine-design mechanical-engineering assembly-design coupling manufacturing-drawing power-transmission
