Industrial IP66 Stainless Steel Electrical Control Cabinet | Sheet Metal Design & Manufacturing
Designed a manufacturing-ready stainless steel electrical control cabinet for industrial automation applications. The enclosure was engineered using sheet metal best practices with a focus on manufacturability, structural rigidity, ease of assembly, and environmental protection.
Scope
Complete sheet metal design
Weldment design
Bend allowance optimization
Mounting plate
DIN rail layout
Cable management
Ventilation system
Door reinforcement
Locking mechanism
Gasket channel
Manufacturing drawings
DXF flat patterns
Assembly documentation
Exploded view
FEATURE
IP66 Sealing
Stainless Steel 304
Sheet Metal Bends
Welded Frame
Hinged Door
Lock Handle
Adjustable Mounting Plate
Cable Glands
Ventilation Louvers
Removable Side Panels
Reinforced Structure
Production Ready
SOFTWARE
SolidWorks
Autodesk Inventor
Fusion 360
Deliverables
STEP
DXF
PDF Drawings
Sheet Metal Flat Patterns
Assembly
Exploded View
BOM
SKILL
Sheet Metal Design
Electrical Enclosure
Industrial Cabinet
Manufacturing Drawings
Mechanical Design
DFM
Weldment
Laser Cutting
Bending
Assembly Design
