Heat Exchanger for Brewery Wort

Report
Designed a heat exchanger with a colleague for a local brewery. They requested that the heat exchanger should have a high volume capacity so that they could use the same heat exchanger when they increase output volume. 30 tubes, 23 passes. Ethylene Glycol or chilled distilled water as working fluid.
