Heat Exchanger: As-Designed vs. As-Built Validation

A side-by-side comparison demonstrating the high spatial accuracy between the 3D CAD model and the final physical installation. This project highlights precise nozzle orientation, saddle placement, and clearance verification to ensure zero-clash integration during the rigging process.
