DYING SHADE & WARE HOUSE

This project involves the architectural and functional layout planning for a Dying Shade and Storage Warehouse facility, located on a rectangular plot measuring 180 feet by 260 feet (46,800 square feet). The facility is designed to optimize space for textile processing and efficient goods storage, along with supporting infrastructure for staff circulation, ventilation, and material flow. 🧱 Key Features: 🔹 Plot Area: Total Plot Size: 180' x 260' Total Area: 46,800 sq.ft. 🔹 Zones Included: Dyeing Shade Area: Covered shed with open sides or adjustable ventilation Space for fabric dying, drying racks, and movement paths Sloped RCC or steel shed roof for proper drainage Main Warehouse Area: Enclosed storage area for finished & raw goods Clear height for stacking (6m+), mechanical loading space Docking & unloading zone Utility Block: Staff toilets & changing rooms Electrical/control room Small office/monitoring room Circulation & Parking: Driveway loop for trucks Separate entry-exit Fire escape routes On-site parking zones for workers and delivery vehicles Structural Frame: Pre-engineered steel or RCC portico system Industrial-grade concrete flooring
