Clicky Sauce Cup - Switch Housing Mechanism

Report
Functional 3D printable sauce cup with integrated clicky switch mechanism. Designed in CATIA V5 with proper tolerances for FDM printing. Features: snap-fit housing for 14x14mm tactile switch, wall thickness 2mm, assembly fit analysis. Focused on precise gap/flush and manufacturability.
Published
in Product Design 3D Printing Services CATIA Design Services
cad catia 3d-printing mechanical-design fdm product-desgin tolerance-analysis switch-housing
