Automotive Rear Window Louvre – Precision Aero Replica

A high-fidelity CAD reconstruction of a classic automotive rear window louvre. This project showcases the ability to reverse-engineer complex surfaces while maintaining structural integrity and aerodynamic flow. Key Technical Features: Surface Continuity: Designed with Class-A surfacing techniques to ensure smooth light reflections and airflow. Fitment Accuracy: Engineered to match OEM mounting points for a seamless bolt-on installation. Material Optimization: Optimized for lightweight ABS plastic injection molding or carbon fiber vacuum bagging. Assembly Detail: Includes a full breakdown of mounting brackets and vibration-dampening interfaces.
