56 mm shock absorber · assembly, exploded view and drawings of the six parts

A 9.8 stroke and a preload adjustable from 0 to 6.6 with a knurled nut 14 across; 54.3 long compressed and 46.75 between eye centres. Assembly with a section and a shaded isometric view at 2:1, exploded view with the six numbered items and a manufacturing drawing per part: body, pivot ball, rod with ball joint, preload nut, spring and spring retainer.
